053248 custom CPU on Konami boards

[VectorGlow]

From my research the following Konami boards use the 053248 custom CPU -

Parodius Da!

Surprise Attack
Crime Fighters 2
Escape Kids
Rollergames
The
Simpsons
Vendetta

Does anyone know if any other Konami boards use it?

It looks like this:

http://i880.photobucket.com/albums/ac8/chinitosoccer/100_6755_zps07b825cc.jpg

I need one for a Parodius Da! (the original chip was well and truly fried). So if anyone has a booting Konami parts board with one I'd be happy to buy it from you.

Also, is it the case that the Konami 052526 and 052001 CPUs are 'mostly' the same as the 053248 ? Are they interchangeable? I ask as this was mentioned on system16.com -

https://www.system16.com/konami_customchips.php

VectorGlow2019-09-09 16:34:18



[Ace`]

iirc 052526 has more address lines than 052001, so replacing a 052001 with 052526 might be possible but not vice versa. 053248 is in a small surface mount package unlike the other two.



[VectorGlow]

I see, thanks. I hadn't looked for images of the 052001 or 052526 so wasn't aware of the physical difference between them and the 053248



[Monstermug]

golfing greats 2 might have that and it's a cheap pcb



[VectorGlow]

Thanks but have just checked MAME and other sources but it doesn't use it.
