I have made some more new parts at work today.
I needed to make new steering opto plates, as one of the plastic ones fell in 2 bits when I undid the screw...
Anyways, here's the CNC program, so you can see what they look like...
%
O666
(PT NO.=DEATH 666-1)
(CUSTOMER=VIRTVIC ARCADE)
(TITLE=DEATH RACE STEERING OPTO WHEEL)
(ISSUE=0)
(OPERATION=OP 1 OF 1)
(MATERIAL SPEC=ALLY PLATE)
(MATERIAL SIZE=90MM SQUARE x 2.6MM THICK)
(METHOD=HOLD ON FIXTURE - BOLT THRU OUTER HOLES)
(TOOLING=ALLY FIXTURE)
(DESCRIPTION OF OP=HOLE & PROFILE COMPLETE)
( )
(DATUM=G54)
(XY0.=CENTRE)
(Z0.=TOP FACE OF MATERIAL)
( )
(T1=3MM CARBIDE SLOTDRILL)
( )
G17 G21 G40 G80 G90
( )
N1 (3MM CARBIDE SLOTDRILL)
T1 M06
G0 G53 Z0 M8
G54 X0. Y0. S12000 M03
G43 H1 D1 Z20.
Z1.
G01 Z-3. F100.0
G13 I1.9 F100 L2
G00 Z1.
X16.838 Y40.651
G01 Z-1.55
G41 X15.07 Y40.301 F500.0
G03 X15.881 Y38.341 I1.386 J-0.574
G02 X22.953 Y34.575 I-15.881 J-38.341
X23.077 Y33.859 I-0.277 J-0.417
G01 X17.288 Y26.091
G03 X17.604 Y23.982 I1.204 J-0.897
G02 X23.982 Y17.604 I-17.604 J-23.982
G03 X26.091 Y17.288 I1.211 J0.889
G01 X33.859 Y23.077
G02 X34.575 Y22.953 I0.299 J-0.401
X40.678 Y8.218 I-34.575 J-22.953
X40.26 Y7.624 I-0.49 J-0.099
G01 X30.674 Y6.224
G03 X29.406 Y4.51 I0.217 J-1.486
G02 X29.406 Y-4.51 I-29.406 J-4.51
G03 X30.674 Y-6.224 I1.485 J-0.228
G01 X40.26 Y-7.624
G02 X40.678 Y-8.218 I-0.072 J-0.495
X34.575 Y-22.953 I-40.678 J8.218
X33.859 Y-23.077 I-0.417 J0.277
G01 X26.091 Y-17.288
G03 X23.982 Y-17.604 I-0.897 J-1.204
G02 X17.604 Y-23.982 I-23.982 J17.604
G03 X17.288 Y-26.091 I0.889 J-1.211
G01 X23.077 Y-33.859
G02 X22.953 Y-34.575 I-0.401 J-0.299
X8.218 Y-40.678 I-22.953 J34.575
X7.624 Y-40.26 I-0.099 J0.49
G01 X6.224 Y-30.674
G03 X4.51 Y-29.406 I-1.486 J-0.217
G02 X-4.51 Y-29.406 I-4.51 J29.406
G03 X-6.224 Y-30.674 I-0.228 J-1.485
G01 X-7.624 Y-40.26
G02 X-8.218 Y-40.678 I-0.495 J0.072
X-22.953 Y-34.575 I8.218 J40.678
X-23.077 Y-33.859 I0.277 J0.417
G01 X-17.288 Y-26.091
G03 X-17.604 Y-23.982 I-1.204 J0.897
G02 X-23.982 Y-17.604 I17.604 J23.982
G03 X-26.091 Y-17.288 I-1.211 J-0.889
G01 X-33.859 Y-23.077
G02 X-34.575 Y-22.953 I-0.299 J0.401
X-40.678 Y-8.218 I34.575 J22.953
X-40.26 Y-7.624 I0.49 J0.099
G01 X-30.674 Y-6.224
G03 X-29.406 Y-4.51 I-0.217 J1.486
G02 X-29.406 Y4.51 I29.406 J4.51
G03 X-30.674 Y6.224 I-1.485 J0.228
G01 X-40.26 Y7.624
G02 X-40.678 Y8.218 I0.072 J0.495
X-34.575 Y22.953 I40.678 J-8.218
X-33.859 Y23.077 I0.417 J-0.277
G01 X-26.091 Y17.288
G03 X-23.982 Y17.604 I0.897 J1.204
G02 X-17.604 Y23.982 I23.982 J-17.604
G03 X-17.288 Y26.091 I-0.889 J1.211
G01 X-23.077 Y33.859
G02 X-22.953 Y34.575 I0.401 J0.299
X-8.218 Y40.678 I22.953 J-34.575
X-7.624 Y40.26 I0.099 J-0.49
G01 X-6.224 Y30.674
G03 X-4.51 Y29.406 I1.486 J0.217
G02 X4.51 Y29.406 I4.51 J-29.406
G03 X6.224 Y30.674 I0.228 J1.485
G01 X7.624 Y40.26
G02 X8.218 Y40.678 I0.495 J-0.072
X15.881 Y38.341 I-8.218 J-40.678
G03 X17.841 Y39.153 I0.574 J1.386
G01 G40 X16.838 Y40.651
G0 G53 Z0 M9
G0 G53 Y0.M30
%
